Shipping containers have revolutionized the maritime industry by allowing for efficient and cost-effective transportation of goods. They have become the standard for shipping a wide variety of goods, from consumer products to heavy machinery.
Understanding shipping container dimensions is crucial for proper handling and transportation, as it ensures that the container is loaded and unloaded safely and efficiently and that the goods inside are protected during transit.
Basics Of Shipping Container Dimensions
The standard shipping container dimensions are 20ft and 40ft in length and are defined by ISO 668 which classifies intermodal freight shipping containers. These dimensions refer to the exterior length of the container and include the corner castings and other fittings. The dimensions of a 20ft container are typical:
- Length: 20ft (6.06m)
- Width: 8ft (2.44m)
- Height: 8.5ft (2.59m)
The dimensions of a 40ft container are typical:
- Length: 40ft (12.19m)
- Width: 8ft (2.44m)
- Height: 8.5ft (2.59m)
In addition to the standard 20ft and 40ft sizes, there are also other non-standard shipping container sizes available, such as:
- 10ft
- 30ft
- 45ft
- 53ft
It is worth noting that these non-standard sizes may not be as widely available, and may be more expensive to transport, as they may not fit as easily on container ships or be able to be moved by standard shipping container equipment.
In terms of capacity, a 20ft container typically has a maximum capacity of 33 CBM (Cubic meter) or 1172 cubic feet, and a 40ft container typically have a maximum capacity of 67 CBM (Cubic meter) or 2389 cubic feet.
It is important to note that the interior dimensions of a container may be slightly smaller than the exterior dimensions due to the thickness of the container’s walls.
A comparison of the dimensions of a 20ft and 40ft container will show that the 40ft container is twice the size of the 20ft container.
20ft Shipping Container Dimensions:
| Dimension | Outer (M) | Outer (Ft) | Inner (M) | Inner (Ft) | Door Opening (M) | Door Opening (Ft) |
|---|---|---|---|---|---|---|
| Length | 6.058 | 19.8 | 5.898 | 19.4 | 2.340 | 7’8″ |
| Width | 2.438 | 8 | 2.352 | 7.7 | 2.340 | 7’8″ |
| Height | 2.591 | 8.5 | 2.390 | 7.8 | 2.280 | 7’6″ |
40ft Shipping Container Dimensions:
| Dimension | Outer (M) | Outer (Ft) | Inner (M) | Inner (Ft) | Door Opening (M) | Door Opening (Ft) |
|---|---|---|---|---|---|---|
| Length | 12.192 | 40 | 12.032 | 39.5 | 2.340 | 7’8″ |
| Width | 2.438 | 8 | 2.352 | 7.7 | 2.340 | 7’8″ |
| Height | 2.591 | 8.5 | 2.390 | 7.8 | 2.280 | 7’6″ |
In terms of capacity, a 20ft container typically has a maximum capacity of 33 CBM (Cubic meter) or 1172 cubic feet and a 40ft container typically have a maximum capacity of 67 CBM (Cubic meter) or 2389 cubic feet.
It is important to note that the interior dimensions of a container may be slightly smaller than the exterior dimensions due to the thickness of the container’s walls.
Importance Of Container Dimensions
Shipping container dimensions are crucial for the efficient handling and transportation of goods. The dimensions of a container can greatly impact the loading and unloading process, as well as the number of items that can be transported in a single container.
Understanding these dimensions is important for those involved in the maritime industry, including shipping companies, freight forwarders, and cargo handlers.
The loading and unloading process is greatly affected by container dimensions. If a container is too small for the items being transported, it may not be possible to load them properly, resulting in damage to the cargo. On the other hand, if a container is too large for the items, it may not be filled to capacity, resulting in wasted space and increased costs.
Container dimensions also impact the number of items that can be transported in a single container. A 20ft container, for example, has a capacity of around 33 cubic meters, while a 40ft container has a capacity of around 67 cubic meters.
This means that a 40ft container can hold twice as much cargo as a 20ft container. However, it’s important to note that the capacity of a container can also be affected by factors such as the weight of the cargo and the configuration of the container.
The table below shows the standard capacity of a 20ft and 40ft container in terms of cubic meters and pallets.
| Container size | Capacity (Cubic Meters) | Capacity (Pallets) |
|---|---|---|
| 20ft | 33 | 11 |
| 40ft | 67 | 22 |
It’s important to note that container dimensions also affect the cost of transportation. Larger containers can carry more cargo, which can result in cost savings for the shipper. However, larger containers also require more space on a ship and may be more expensive to transport.
In addition, smaller containers have the advantage of being easier to handle and load and unload, which can also result in cost savings. Therefore, it’s important to consider not only the cost of the container itself but also the cost of transportation when selecting a container size.
Overall, understanding shipping container dimensions is crucial for the proper handling and transportation of goods. By taking into consideration the dimensions of a container, shippers, freight forwarders and cargo handlers can ensure that cargo is loaded and transported safely and efficiently, minimizing damage and reducing costs.
Important Shipping Container Specifications
Container capacity is typically measured in either cubic meters or cubic feet. It is important to understand this measurement when determining the number of goods that can be stored in a container.
The maximum weight a container can carry is also an important consideration. This includes not only the weight of the goods being transported but also the weight of the container itself. This can affect the safety of the items being transported and the stability of the ship during transit.
Container dimensions also play a role in the safety of the items being transported. Properly securing and lashing the containers on a ship is essential to ensure that they remain stable during transit and prevent damage to the goods inside.
To properly lash and secure a container, the ship crew should follow these key steps:
First, the container should be properly positioned on the ship’s deck.
Next, the container should be securely attached to the ship using lashing equipment, such as ropes or chains.
Finally, the container should be checked to ensure that it is properly secured and will not move during transit.
It is also important to consider that the dimensions of the container can affect the berthing of a ship and the way of breaking bulk. The bigger dimensions of the container can affect the loading and unloading process and increase the cost of transportation. When choosing a shipping company like Evergreen Maritime Corporation and its giant container ships, it is important to consider all of these factors to ensure that the shipping process runs smoothly and efficiently.
Quickly about Shipping Container Dimensions
Understanding shipping container dimensions is crucial for the proper handling and transportation of goods in the maritime industry. Standard shipping container dimensions include the 20ft and 40ft containers, with the 20ft container measuring 20 feet in length, 8 feet in width, and 8.5 feet in height, and the 40ft container measuring 40 feet in length, 8 feet in width, and 8.5 feet in height.
Other important specifications to consider include container capacity, measured in cubic meters or cubic feet, maximum weight capacity, and the lashing and securing of containers on a ship for safe transport.
A 20ft shipping container measures 20 feet in length, 8 feet in width, and 8.5 feet in height, with a door opening of 7.5 feet in width and 7.8 feet in height.
On the other hand, a 40ft shipping container measures 40 feet in length, 8 feet in width, and 8.5 feet in height, with a door opening of 7.5 feet in width and 7.8 feet in height.
FAQ
What are the standard dimensions of a 20ft shipping container?
The standard dimensions of a 20ft shipping container are approximately 20 feet in length, 8 feet in width, and 8.5 feet in height.
What are the standard dimensions of a 40ft shipping container?
The standard dimensions of a 40ft shipping container are approximately 40 feet in length, 8 feet in width, and 8.5 feet in height.
Are there other non-standard shipping container sizes available?
Yes, apart from the standard 20ft and 40ft sizes, there are other non-standard shipping container sizes available, such as 10ft, 30ft, 45ft, and 53ft. However, these non-standard sizes may not be as widely available and could be more expensive to transport due to potential limitations in fitting on container ships or using standard shipping container equipment.
How does the capacity of a 20ft container compare to that of a 40ft container?
A 20ft container typically has a maximum capacity of approximately 33 cubic meters (1172 cubic feet), while a 40ft container typically has a maximum capacity of around 67 cubic meters (2389 cubic feet). Therefore, a 40ft container can hold approximately twice as much cargo as a 20ft container.
How do container dimensions affect the cost of transportation?
Container dimensions can impact the cost of transportation. Larger containers can carry more cargo, resulting in potential cost savings for the shipper. However, larger containers also require more space on a ship and may be more expensive to transport. Smaller containers, although having less capacity, can be easier to handle and load/unload, which can lead to cost savings. When selecting a container size, it’s important to consider not only the container’s cost but also the cost of transportation.
